92-22006 บ่าวาล์วไอเสีย VOLVO D7A/D7C KS GERMANY แท้
Product description
|
Dimensions
|
|
| Type | exhaust |
| Packing unit | 2 |
| Material | G1 High temperature resistant |
| Valve seat angle (α) | 45° |
| Outside diameter (D) | 43.6 mm |
| Inside diameter (d) | 35.0 mm |
| Height (H) | 7.9 mm |
| Outside diameter (D) | 1.717 inch |
| Inside diameter (d) | 1.378 inch |
| Height (H) | 0.311 inch |
Reference numbers
| DEUTZ | 0420 0171 | ||
| DEUTZ | 0425 2443 | ||
| VOLVO | 20459963 | ||
| VOLVO | 20845144 |
KS recommends the following press fittings
| Outer Diameter Valve seat insert | Material Cylinder Head Cast iron | Material Cylinder Head aluminium | |||
| [mm] | [inch] | [mm] | [inch] | [mm] | [inch] |
| 20 – 30 | 0.7874 -1.1811 | 0,06 | 0.0024 | 0,08 | 0.0031 |
| 30 – 40 | 1.1811 -1.5748 | 0,08 | 0.0031 | 0,105 | 0.0040 |
| 40 – 50 | 1.5748 -1.9685 | 0,10 | 0.0040 | 0,12 | 0.0047 |
| 50 – 60 | 1.9685 -2.3622 | 0,12 | 0.0047 | 0,14 | 0.0055 |
| 60 – 70 | 2.3622 -2.7559 | 0,14 | 0.0055 | 0,16 | 0.0063 |
